GS180

Gateway

The GS180 is a high-performance intelligent bridge that serves as the central hub for your smart home ecosystem. Powered via a 5V DC Type-C connection, it seamlessly integrates advanced Wi-Fi 6 and Bluetooth 5 protocols to deliver exceptional networking stability and speed. By connecting to the FireAngel platform and APP, it efficiently manages BLE Mesh sub-devices, enabling comprehensive remote monitoring, control, and local debugging directly from your smartphone.

Bullet Points

Advanced Dual-Protocol Networking

Integrates high-speed Wi-Fi 6 (2.4G & 5G) and Bluetooth 5 technology to provide a stable, efficient, and low-latency connection for your entire smart home.

BLE Mesh Central Hub

Acts as the intelligent core of your home security system, seamlessly connecting and managing multiple BLE Mesh sub-devices for unified remote control via the APP.

Smart Speaker Compatibility

Easily integrates into broader smart ecosystems, offering full compatibility with mainstream voice assistants from Google, Apple, and Amazon for hands-free control.

Intuitive Physical Controls

Equipped with four dedicated shortcut buttons (Positioning, Test, Arm/Disarm, Network) and clear LED indicators, allowing for quick and direct local operation.

Smart Child-Lock Protection

Features an automatic child-lock mechanism that secures the physical buttons after 20 seconds of inactivity, preventing accidental triggers and ensuring system stability.

10-Year Reliable Lifespan

Constructed from flame-retardant PC+ABS materials (UL94V-0) and engineered for durability, guaranteeing up to 10 years of continuous, stable operation.

Key Specifications

Power Supply	DC 5V (USB Type-C)
Standby Power	< 5W
Wireless Protocol	Wi-Fi 6 & Bluetooth Mesh
Wi-Fi Frequency	2.4GHz (24122484MHz) & 5GHz (51805885MHz)
Bluetooth Version	Bluetooth 5
User Interface	4x Operation Buttons, 1x Tri-Color Logo LED, 4x Button LEDs
Product Life	10 Years
Operating Temperature	-10°C to +50°C
Humidity Range	≤ 95% RH (Non-condensing)
Material	PC+ABS (UL94V-0 Flame-retardant)
Dimension	70mm x 70mm x 21mm
Compliance Standard	EN 303 645, EN 18031, EN 62368-1, RoHS, REAC

Usage Scenarios

Centralized Management

Serves as the reliable central hub of your home, bridging all your BLE Mesh security sensors and alarms to the cloud for unified APP control.

Voice Assistant Integration

Connects your security ecosystem to Google, Apple, or Amazon smart speakers, allowing you to check system status using simple voice commands.

Direct Local Control

Use the dedicated physical buttons to quickly arm or disarm your security system as you leave or enter the house, without needing your smartphone.

Smart Hub

Voice Control

Local Operation

Why Siterwell

With over a decade of expertise in IoT and safety technology, Siterwell partners with businesses worldwide to create smarter, safer living environments.

Backed by strong R&D capability, global certifications, and a 56,000 m² production base, we deliver both innovation and reliable large-scale manufacturing.
From award-winning designs to proven global delivery across Asia, Europe, and the US, we focus on building long-term partnerships that drive mutual growth and success.
