DESCRIPTION
Smart Radiator Thermostat (GS361A-H04), using dry battery power supply, without wiring, easy installation, for the temperature control of warm water radiator, provide comfort- able temperature, reduce energy waste, save the cost of heating users. This product has a built-in zigbee® (Tuya) wireless communication module with low power and LCD display screen. It can be used individually and can be added to the TuyaSmart APP to make it an intelligent thermostat. After joining the TuyaSmart system, you can select the mode, set the temperature, set the child lock and set the window detection function in APP. Any operation at the device side will also be synchronized to APP, such as setting temperature manually.
New Upgrade +9
APP & Voice Control
Al Voice control: Amazon Alexa, Google Home
Use the following voice commands:
Turn up/Turn of
Temperature setting
Turn up the heat
Turn the heat up to 25 degrees
Turn of the heat
Turn the heat up ive degrees for me
Anti-freezing and Anti-scaling
Anti-freezing: When the device detects that the indoor temperature is less than 5C, it will automatical-ly run the anti-freezing function to prevent the water pipes from being frozen and cracked. Anti-scaling: The device will automatically switch the valve on and of once a month during the warm season (April. Mav. June) to prevent the valve from accumulating scale. and avoid clogging.
Window detection and linkage with other smart devices
Window detection: Open window detection function, when the window is detected open, the device will close the valve for 30 minutes to stop heat dissipation and redu heat loss External Temperature Reading: Receive the temperature readings directly from the connected room thermometer. Scene linkage: Linkage of door and window sensors, when the door/window is detected to be open, automatically close the valve: linkage of PlR sensors. when the room is detected to be occupied, automatically turn on the "at home" temperature.
Group Control Function
Combine devices in diferent rooms to form a control group for simultaneous control.
Zigbee 3.0 StandardCompatible
Works with Zigbee 3.0 gateway to connect to WiFi.
Smart Temperature Calibration
The device is installed on the heater and the temperature collected is somewhat of from the actualtemperature of the room. You can set the temperature ofset to improve temperature accuracy
Smart Schedules
Set the target control temperature for 7 days and support 6 timeslots to set the temperature daily for automatic temperature control.
Tuya APP &Historical data query
New TuyaAPP UI, Intuitive and lexible operation, and added functions such as historical data query.
Child Lock
Open the child lock function, you can lock the keys on the device to prevent misuse by children, resulting in abnormal operation of the device,i.e., reduce heat loss.
Speciication
| Power input: | DC3V(AA×2, Alkalinity) |
| Battery life: | 2 years |
| Standby current: | ≤100μA |
| Maximum current: | ≤800mA |
| Protocol: | ZigBee® |
| Wireless distance: | ≥30meters @in an open air |
| Setting temperature: | Automatic mode 5~30℃ Manual mode 5~30℃ Anti-freezing mode 5~15℃ |
| Measurement : | Once every 2 minutes. |
| Valve stroke: | 6mm as longest |
| Noise level: | <30dB(A) |
| Environment: | -20~65℃, ≤95%RH Non-condensate |
| Environmental standards : | RoHS |
| Size: | Φ57×89mm |
| Interface nut: | M30×1.5mm |
| Adapter: | M30×18.5mm；M30×8.8mm；Φ41×23.5mm； |
| Weight: | 192g (Include batteries) |
